ATEN
ATEN VM0202H-AT-G Matrix Switch AV Matrix Switch
10.2 Gbit/s 340 MHz AV Matrix Switch, Black
Max. resolution: 4096 x 2160 px
HDCP Device Software Updates
Rack-mounting options
Specification
Features
Product type:
Product subcategory.
AV matrix switcher
Data transfer speed:
The speed at which data can be transmitted to MC, expressed in units per second, may vary depending on the network configuration.
10.2 Gbit/s
3D Compatibility:
The device can be used with 3D technology.
Yes
Case color:
The color of the case, which is a rigid cover that protects the device inside.
Black
Extended Display Identification Data (EDID):
Yes
Display
Maximum pixel clock:
340 MHz
Processor
Max. resolution:
Maximum number of pixels in an image. This is usually specified as width x height; for example, "1024 x 768" means a width of 1024 pixels and a height of 768 pixels.
4096 x 2160 px
Management Features
Device software updates:
Yes
Ports and Interfaces
Number of HDMI input ports:
2
HDCP:
High-bandwidth Digital Content Protection (HDCP) is a form of protection against the copying of digital audio and video content during its transmission
Yes
HDCP version:
1.4
Supported USB type:
Type of USB port built into the device.
Micro-USB
Port RS-232:
Number of RS-232 ports. The RS-232 serial port was once a standard feature of personal computers, used for modems, printers, mice, uninterruptible power supplies, and other peripheral devices. Today, this port has largely been replaced by USB and other ports.
1
Number of HDMI output ports:
2
DC output jack:
Connecting the device to a power source.
Yes
Performance
Supported resolutions:
4096 x 2160, 3840 x 2160
Structure
Built-in display:
The display is part of the device, so no additional hardware needs to be connected.
No
Check type:
How to operate the device.
Buttons
Rack-mounting options:
A type of mounting that secures devices to shelves and stands.
Yes
Case material:
The material the product's casing is made of.
Metal
Power
Power consumption:
The amount of energy consumed by this model, expressed in watts. Typical values provided by manufacturers include energy consumption in idle mode, standby/sleep mode, typical use, and maximum use.
4.3 W
Ergonomics
LEDs:
Yes
Weight and Dimensions
Product weight:
Product weight without packaging (net). Whenever possible, the net weight is listed together with the weight of the equipment’s standard accessories. Please note that some manufacturers define the product weight as that of a single unit, excluding the weight of accessories and/or supplies.
840 g
Product depth:
Distance from the front to the back of the item.
76 mm
Product height:
Product height.
42 mm
Product width:
Width measurement.
200 mm
Packaging data
AC power adapter:
Yes
Weight including packaging:
Weight of the packaged product in grams.
980 g
Package width:
The distance from one side of the package to the other.
59 mm
Package depth:
Distance from the beginning to the end of the package.
239 mm
Package height:
Distance from the top to the bottom of the package.
160 mm
Package Contents
Remote control included:
Remote Control Function Description
Yes
User Manual:
Yes
Hook Installation Kit:
Yes
Infrared receiver included:
Yes
Working Conditions
Temperature range (operating):
The minimum and maximum temperatures at which the device can be used safely.
0–40 °C
Temperature range (storage):
The minimum and maximum temperatures at which the device can be safely stored.
-20 to 60 °C
Relative humidity range:
0 - 80%
Permissible relative humidity:
0 - 80%
Logistics data
Width of the collection box (external):
250 mm
Length of the main (outer) box:
325 mm
Height of the reference box (external):
175 mm
Net weight in the bulk package:
4.2 kg
Harmonized System (HS) code:
85299097
Gross weight of the main (outer) case:
5.33 kg
Products in the main (outer) box:
5 items
Other features
Number of USB ports:
1
