AXAGON
Axagon RVD-HI adapter kablowy DisplayPort HDMI Czarny
DisplayPort Straight Male
HDMI Straight Female
1920 x 1200 px
Black
Axagon RVD-HI adapter kablowy DisplayPort HDMI Czarny
AXAGON RVD-HI DisplayPort to HDMI Adapter for connecting an HDMI monitor, TV, or projector to a computer with a DisplayPort output.
This hardware converter, which requires no installation or setup, ensures high-quality video and audio transmission at resolutions up to 1920x1200 at 60Hz.
Conversions are one-way, i.e., from DisplayPort to HDMI, not the other way around.
Input:
• DisplayPort v1.1
• DP connector with latch (M) male
• connector latch control button
Output:
• HDMI v1.3a
• HDMI A (F) female connector
Supported resolutions:
• max. 1920 x 1200 (16:10) @60Hz WUXGA
• 1920 x 1080 (16:9) Full HD/1080p
• 1680 x 1050 (16:10) WSXGA+
• 1600 x 1200 (4:3) UXGA
• 1600 x 900 (16:9) HD+
• 1440 x 900 (16:10) WXGA+
• 1400 x 1050 (4:3) SXGA+
• 1366 x 768 (16:9) WXGA
• 1360 x 768
• 1280 x 1024 (5:4) SXGA
• 1280 x 960 (4:3) SXGA-
• 1280 x 800 (16:10) WXGA
• 1280 x 768 (5:3) WXGA
• 1280 x 720 (16:9) HD/WXGA/720p
• 1280 x 600
• 1152 x 864 (4:3) XGA+
• 1024 x 768 (4:3) XGA
• 800 x 600 (4:3) SVGA
Additional features:
• Support for audio transmission.
• DDC (Display Data Channel) support—intelligent configuration of resolution, refresh rate, and other parameters based on the source graphics chip.
• Supported modes: duplicate the main monitor’s desktop (default setting), extend the main monitor’s desktop.
• HPD (Hot-Plug-Detect) support—a communication sequence that controls the connection and disconnection of a device while the system is running.
• Support for power-saving mode with sleep mode controlled by the source device (PC) and the display (monitor/TV).
• Bus-powered—no additional external power supply is required.
• Gold-plated connectors for excellent contact and to prevent oxidation.
• The NXP PTN3361BBS chip was used.
• Dimensions: 56 x 24 x 12 mm.
• Weighs only 12g.
• Operating temperature: 0 ~ 40°C.
• Storage temperature: -10 ~ +85°C.
Supported operating systems:
• All versions of MS Windows, Mac OS, Linux, and other operating systems.
• This is a purely hardware-based converter; processing is handled solely by the adapter chip without any involvement from a computer. No drivers are installed, so compatibility is not dependent on the operating system used.
The package includes:
• DisplayPort to HDMI adapter,
• Packaged in a cardboard box.
This hardware converter, which requires no installation or setup, ensures high-quality video and audio transmission at resolutions up to 1920x1200 at 60Hz.
Conversions are one-way, i.e., from DisplayPort to HDMI, not the other way around.
Input:
• DisplayPort v1.1
• DP connector with latch (M) male
• connector latch control button
Output:
• HDMI v1.3a
• HDMI A (F) female connector
Supported resolutions:
• max. 1920 x 1200 (16:10) @60Hz WUXGA
• 1920 x 1080 (16:9) Full HD/1080p
• 1680 x 1050 (16:10) WSXGA+
• 1600 x 1200 (4:3) UXGA
• 1600 x 900 (16:9) HD+
• 1440 x 900 (16:10) WXGA+
• 1400 x 1050 (4:3) SXGA+
• 1366 x 768 (16:9) WXGA
• 1360 x 768
• 1280 x 1024 (5:4) SXGA
• 1280 x 960 (4:3) SXGA-
• 1280 x 800 (16:10) WXGA
• 1280 x 768 (5:3) WXGA
• 1280 x 720 (16:9) HD/WXGA/720p
• 1280 x 600
• 1152 x 864 (4:3) XGA+
• 1024 x 768 (4:3) XGA
• 800 x 600 (4:3) SVGA
Additional features:
• Support for audio transmission.
• DDC (Display Data Channel) support—intelligent configuration of resolution, refresh rate, and other parameters based on the source graphics chip.
• Supported modes: duplicate the main monitor’s desktop (default setting), extend the main monitor’s desktop.
• HPD (Hot-Plug-Detect) support—a communication sequence that controls the connection and disconnection of a device while the system is running.
• Support for power-saving mode with sleep mode controlled by the source device (PC) and the display (monitor/TV).
• Bus-powered—no additional external power supply is required.
• Gold-plated connectors for excellent contact and to prevent oxidation.
• The NXP PTN3361BBS chip was used.
• Dimensions: 56 x 24 x 12 mm.
• Weighs only 12g.
• Operating temperature: 0 ~ 40°C.
• Storage temperature: -10 ~ +85°C.
Supported operating systems:
• All versions of MS Windows, Mac OS, Linux, and other operating systems.
• This is a purely hardware-based converter; processing is handled solely by the adapter chip without any involvement from a computer. No drivers are installed, so compatibility is not dependent on the operating system used.
The package includes:
• DisplayPort to HDMI adapter,
• Packaged in a cardboard box.
Specification
Features
API Size 1:
Simple
API Size 2:
Simple
Contact surface material:
The top layer covering the network interface.
Gold
Connector 1:
The first port on the device.
DisplayPort
Connector 2:
Second port on the device.
HDMI
Interface 1:
The gender of the first connector of the product. Each half of a pair of mating connectors is designated as male or female; the part that has a socket or fits into another is called male.
Men's
Interface 2:
The gender of the second connector of the product. Each half of a pair of mating connectors is designated as male or female; the indented one—or the one that fits around the other—is called female.
Female
Refresh at maximum resolution:
60 Hz
Set of layouts:
Chipset for this configuration, expressed as the manufacturer’s name and the product’s proprietary name.
NXP PTN3361BBS
Converter type:
Active video converter
Certificates:
CE, RoHS
Video
Supported image resolutions:
The display resolution that can be shown on a screen. Resolution describes the width and height of a screen, such as a computer screen, and is expressed in pixels.
800 x 600 (SVGA), 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 768 (WXGA), 1280 x 800 (WXGA), 1280 x 960, 1360 x 768 (WXGA), 1366 x 768, 1400 x 1050 (SXGA+), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Supported video modes:
Video modes supported by the device.
720p, 1080p
Processor
Max. resolution:
Maximum number of pixels in an image. This is usually specified as width x height; for example, "1024 x 768" means a width of 1024 pixels and a height of 768 pixels.
1920 x 1200 px
Ports and Interfaces
HDMI version:
1.3a
DisplayPort version:
1.1
Structure
Product color:
Color, e.g., red, blue, green, black, white.
Black
System Requirements
Supported operating systems: Windows:
The version of Windows that can be used with this device.
Yes
Supported operating systems: Mac:
A Mac operating system, such as OS X, that can be used with this device.
Yes
Supported operating systems: Linux:
8 RT. Linux (9.4, 9.5), Red Hat Enterprise Linux 5.0 (supported with a pre-built package); SUSE Linux (10.3, 11.0, 11, 11.1, 11.2), Fedora (9, 9.0, 10, 10.0, 11.0, 11, 12, 12.0), Ubuntu (8.04, 8.04.1, 8.04.2, 8.10, 9.04, 9.10, 10.04), Debian (5.0, 5.0.1, 5.0.2, 5.0.3)
Yes
Ergonomics
Plug & Play support:
Indicates whether a given product supports the "plug & play" feature. Plug & play refers to a type of device or software that can be used immediately after it is connected, as opposed to devices or software that require configuration.
Yes
Weight and Dimensions
Product weight:
Product weight without packaging (net). Whenever possible, the net weight is listed together with the weight of the equipment’s standard accessories. Please note that some manufacturers define the product weight as that of a single unit, excluding the weight of accessories and/or supplies.
12 g
Product depth:
Distance from the front to the back of the item.
24 mm
Product height:
Product height.
12 mm
Product width:
Width measurement.
56 mm
Packaging data
Weight including packaging:
Weight of the packaged product in grams.
51 g
Package width:
The distance from one side of the package to the other.
140 mm
Package depth:
Distance from the beginning to the end of the package.
88 mm
Package height:
Distance from the top to the bottom of the package.
36 mm
Package type:
Product packaging type, e.g., box.
Hanging box
Package Contents
Quantity per package:
1 item
User Manual:
Yes
Working Conditions
Temperature range (operating):
The minimum and maximum temperatures at which the device can be used safely.
0–40 °C
Temperature range (storage):
The minimum and maximum temperatures at which the device can be safely stored.
-10 to 85 °C
Logistics data
Country of origin:
Country where the product was manufactured.
China
Certificates
Certificates of Conformity:
Indicates which regulatory, safety, and environmental standards the product complies with, as verified by recognized authorities or certification bodies.
RoHS, CE
