DIGITUS
Digitus 24-port Fast Ethernet PoE switch
24 10/100Base-TX ports with PoE support
2-port Gigabit TP/SFP Combo Uplink Connector
Compliance with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.3af, and IEEE 802.3at network standards
PoE output power: 55 V DC, max. 30 W per port
Digitus 24-port Fast Ethernet PoE switch
Integrated Power over Ethernet (PoE) solution for small and medium-sized networks
- 24 10/100Base-TX ports with PoE support
- 2-port Gigabit TP/SFP Combo Uplink connector
- Maximum PoE power of 370 W
- One-click support for VLAN and CCTV modes
- Supports the PD-ALIVE feature
DIGITUS® Fast Ethernet PoE switches are designed for medium- and large-scale network systems. The PoE feature and 19'' form factor facilitate network integration. These switches are an excellent choice for improving network performance and efficiency.
- 24 10/100Base-TX ports with PoE support
- 2-port Gigabit TP/SFP Combo Uplink connector
- Maximum PoE power of 370 W
- One-click support for VLAN and CCTV modes
- Supports the PD-ALIVE feature
DIGITUS® Fast Ethernet PoE switches are designed for medium- and large-scale network systems. The PoE feature and 19'' form factor facilitate network integration. These switches are an excellent choice for improving network performance and efficiency.
Specification
Data Transfer
Routing/switching bandwidth:
Amount of data transferred per second.
8.8 Gbit/s
Transmission speed:
6.5 Mpps
Size of the address table:
The size of the address table for this configuration, expressed in the number of entries.
16,384 entries
Packet throughput (1 Gbps):
1,488,095 pps
Packet transmission range (10 Mbps):
14,881 pps
Packet throughput (100 Mbps):
148,810 pps
Power over Ethernet (PoE)
Number of Fast Ethernet (PoE) ports:
24
Total Power over Ethernet (PoE) budget:
370 W
Features
Designed for outdoor use:
The product can be used outdoors.
No
Network
10G support:
The product may use Oracle 10G, a database management system released in 2003.
No
Copper Ethernet Cabling Technology:
10BASE-T, 100BASE-TX, 1000BASE-T
Communication Standards:
Network standards, e.g., IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.
IEEE 802.3at
Ethernet interface type:
Fast Ethernet
VLAN support:
A virtual local area network (VLAN) consists of several computers and switches. It is a computer network that is logically separated within another, larger physical LAN.
Yes
Management Features
Switch type:
The type of switch the device has.
Unmanaged
Ports and Interfaces
Basic RJ-45 Switching Number of Ethernet Ports:
Number of RJ-45 Ethernet ports.
24
Basic Ethernet RJ-45 port types:
RJ-45 Ethernet port (connector) type/category.
Fast Ethernet (10/100)
Number of SFP Combo ports:
2
Performance
MTBF (Mean Time Between Failures):
A statistical model used to demonstrate the reliability of a product or mechanism; expressed in hours and as a percentage of the operating cycle. This figure (in hours) does not represent the mean time to failure for a given mechanism or unit.
50,000 h
Structure
Layout:
Description of the product’s external features.
1U
Number of fans:
Number of fans (a device with rotating blades that generates airflow for ventilation or cooling).
2 went.
Rack-mounting options:
A type of mounting that secures devices to shelves and stands.
Yes
Vandal-resistant:
This product is intended for use and installation in a location (or on a device) that is vulnerable to vandalism.
No
Product color:
Color, e.g., red, blue, green, black, white.
Black, Silver
Power
AC input voltage:
Electrical voltage.
100 - 240 V
AC input frequency:
50 - 60 Hz
PoE Support:
The device supports Power over Ethernet (PoE), a technology that transmits electrical power via Ethernet cables to network-connected peripheral devices. This allows both data and electrical power to be transmitted to devices such as wireless access points or IP cameras via a single cable.
Yes
Ergonomics
LEDs:
Function, Link, PoE, Power
Weight and Dimensions
Product depth:
Distance from the front to the back of the item.
207 mm
Product height:
Product height.
44 mm
Product width:
Width measurement.
440 mm
Packaging data
Weight including packaging:
Weight of the packaged product in grams.
4.67 kg
Package capacity:
11181.2 cm³
Package width:
The distance from one side of the package to the other.
493 mm
Package depth:
Distance from the beginning to the end of the package.
315 mm
Working Conditions
Temperature range (operating):
The minimum and maximum temperatures at which the device can be used safely.
0–40 °C
Temperature range (storage):
The minimum and maximum temperatures at which the device can be safely stored.
-40 to 70 °C
Relative humidity range:
10 - 90%
Permissible relative humidity:
5 - 90%
Logistics data
Country of origin:
Country where the product was manufactured.
China
Harmonized System (HS) code:
85176990
Mask with serial number:
85176200
