DIGITUS
Digitus HDMI Splitter, 1x2, 4K / 30 Hz
The solution transmits an HDMI input signal to two output displays with a maximum resolution of 4K 2K / 30Hz
EDID support (2 modes) – 1: Copy – HDMI 1 output / 2: Auto mode – Compare & Create – HDMI 1 and 2 outputs
HDMI 1.4b
HDCP 1.4
Digitus HDMI Splitter, 1x2, 4K / 30 Hz
The solution transmits an HDMI input signal to two output displays with a maximum resolution of 4K 2K / 30Hz
- Display an HDMI input signal on two output displays simultaneously at 4K / 30 Hz
- EDID support (2 modes) – 1: Copy – HDMI 1 output / 2: Auto mode – Compare & Create – HDMI 1 and 2 outputs
- HDMI 1.4b
- HDCP 1.4
- Video bandwidth: 2.97 Gbps
- Compact design for easy and flexible installation
The device transmits an HDMI input signal to two output displays. Supports resolutions up to 4K 2K / 30 Hz. Using the EDID switch, you can select two modes (Clone: HDMI Output 1 / Auto Mode: Automatically compares HDMI outputs 1 and 2, generates a new EDID, and sends it back to the HDMI input).
- Display an HDMI input signal on two output displays simultaneously at 4K / 30 Hz
- EDID support (2 modes) – 1: Copy – HDMI 1 output / 2: Auto mode – Compare & Create – HDMI 1 and 2 outputs
- HDMI 1.4b
- HDCP 1.4
- Video bandwidth: 2.97 Gbps
- Compact design for easy and flexible installation
The device transmits an HDMI input signal to two output displays. Supports resolutions up to 4K 2K / 30 Hz. Using the EDID switch, you can select two modes (Clone: HDMI Output 1 / Auto Mode: Automatically compares HDMI outputs 1 and 2, generates a new EDID, and sends it back to the HDMI input).
Specification
Features
Operating voltage:
5 V
Output current:
1 A
Data transfer speed:
The speed at which data can be transmitted to MC, expressed in units per second, may vary depending on the network configuration.
2.97 Gbit/s
Extended Display Identification Data (EDID):
Yes
Easy installation:
Yes
Display
Maximum refresh rate:
30 Hz
Video
HD Type:
Type of high-definition supported (e.g., Full HD, 4K Ultra HD).
4K Ultra HD
Processor
Max. resolution:
Maximum number of pixels in an image. This is usually specified as width x height; for example, "1024 x 768" means a width of 1024 pixels and a height of 768 pixels.
3840 x 2160 px
Ports and Interfaces
Video port type:
The type of port on the device for connecting a video device, e.g., SCART.
HDMI
Number of video ports:
Number of video input and output ports.
3
HDMI version:
1.4b
Structure
Case material:
The material the product's casing is made of.
Metal
Product color:
Color, e.g., red, blue, green, black, white.
Black
Ergonomics
Plug & Play support:
Indicates whether a given product supports the "plug & play" feature. Plug & play refers to a type of device or software that can be used immediately after it is connected, as opposed to devices or software that require configuration.
Yes
Weight and Dimensions
Product weight:
Product weight without packaging (net). Whenever possible, the net weight is listed together with the weight of the equipment’s standard accessories. Please note that some manufacturers define the product weight as that of a single unit, excluding the weight of accessories and/or supplies.
125 g
Product depth:
Distance from the front to the back of the item.
70 mm
Product height:
Product height.
20 mm
Product width:
Width measurement.
60 mm
Packaging data
AC power adapter:
Yes
Weight including packaging:
Weight of the packaged product in grams.
281.75 g
Package capacity:
798,525 cm³
Package width:
The distance from one side of the package to the other.
117 mm
Package depth:
Distance from the beginning to the end of the package.
105 mm
Package height:
Distance from the top to the bottom of the package.
65 mm
Package Contents
Quantity per package:
1 item
User Manual:
Yes
Working Conditions
Temperature range (operating):
The minimum and maximum temperatures at which the device can be used safely.
0–40 °C
Logistics data
Width of the collection box (external):
350 mm
Length of the main (outer) box:
253 mm
Height of the reference box (external):
445 mm
Country of origin:
Country where the product was manufactured.
China
Mask with serial number:
85437090
Gross weight of the main (outer) case:
11 kg
Products in the main (outer) box:
40 items
Other features
Video playback interface:
2x HDMI
