LEVELONE
LevelOne IGC-0101 1000 Mbit/s network converter
Wired
1000 Mbit/s
10BASE-T, 100BASE-TX, 1000BASE-T
Number of Ethernet LAN (RJ-45) ports: 1
Specification
Data Transfer
Compatible with Jumbo Frames:
Yes
Jumbo Frames Extension:
9000
Power over Ethernet (PoE)
Number of Fast Ethernet (PoE) ports:
1
Total Power over Ethernet (PoE) budget:
30 W
Mouse
Communication technology:
The technology that enables the device to connect, e.g., wired or wireless.
Wired
Features
Maximum data transfer rate:
The maximum speed at which data can be transferred from one device to another.
1000 Mbit/s
Voltage:
The voltage required to power the device.
48 - 56 V
Certificates:
CE, FCC, VCCI, FCC Part 15 Subpart B Class A, CE EN 55022 Class A
Network
Copper Ethernet Cabling Technology:
10BASE-T, 100BASE-TX, 1000BASE-T
Data transfer speed over Ethernet LAN:
Various LAN Ethernet connection speeds in megabits per second.
10, 100, 1,000 Mbit/s
Communication Standards:
Network standards, e.g., IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.
IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Flow control support:
Yes
Ethernet interface type:
Gigabit Ethernet
Ports and Interfaces
Number of Ethernet LAN ports (RJ-45):
Number of Ethernet LAN (RJ-45) ports on the device. Ethernet LAN (RJ-45) ports allow a computer to connect to an Ethernet network.
1
Number of ports:
Number of cable sockets.
1
Performance
Fiber-optic connector:
A fiber optic connector that allows for faster connection and disconnection than splicing. The connectors automatically engage and align the fiber cores so that light can pass through them. Higher-quality connectors lose very little light due to fiber reflection. In total, approximately 100 types of optical fibers have been manufactured.
SFP
MTBF (Mean Time Between Failures):
A statistical model used to demonstrate the reliability of a product or mechanism; expressed in hours and as a percentage of the operating cycle. This figure (in hours) does not represent the mean time to failure for a given mechanism or unit.
500,000 h
Structure
Internal:
The device is built-in or must be built-in (Yes/No). If not, this means that the device is connected externally via a cable or wirelessly.
No
DIN rail mounting:
Yes
Power
Power consumption:
The amount of energy consumed by this model, expressed in watts. Typical values provided by manufacturers include energy consumption in idle mode, standby/sleep mode, typical use, and maximum use.
2 W
PoE Support:
The device supports Power over Ethernet (PoE), a technology that transmits electrical power via Ethernet cables to network-connected peripheral devices. This allows both data and electrical power to be transmitted to devices such as wireless access points or IP cameras via a single cable.
Yes
Ergonomics
LEDs:
Function, Link, Power
Weight and Dimensions
Product weight:
Product weight without packaging (net). Whenever possible, the net weight is listed together with the weight of the equipment’s standard accessories. Please note that some manufacturers define the product weight as that of a single unit, excluding the weight of accessories and/or supplies.
135 g
Product depth:
Distance from the front to the back of the item.
81.5 mm
Product height:
Product height.
103.5 mm
Product width:
Width measurement.
32 mm
Packaging data
Weight including packaging:
Weight of the packaged product in grams.
350 g
Package width:
The distance from one side of the package to the other.
165 mm
Package depth:
Distance from the beginning to the end of the package.
65 mm
Package height:
Distance from the top to the bottom of the package.
215 mm
Package Contents
User Manual:
Yes
Safety regulations and standards
Security:
List of regulatory standards for all countries where this product has been approved.
IEC EN60950-1
Working Conditions
Temperature range (operating):
The minimum and maximum temperatures at which the device can be used safely.
-40 to 75 °C
Relative humidity range:
5 - 95%
Logistics data
Width of the collection box (external):
350 mm
Length of the main (outer) box:
240 mm
Height of the reference box (external):
560 mm
Country of origin:
Country where the product was manufactured.
Taiwan
Harmonized System (HS) code:
85176990
Gross weight of the main (outer) case:
6.6 kg
Products in the main (outer) box:
16 items
