QNAP
QNAP QSW-M5216-1T Managed L2 Network Switch, Black
Managed L2 Management via the website
Quality of Service (QoS)
Console port: RJ-45
10G support
Specification
Data Transfer
Routing/switching bandwidth:
Amount of data transferred per second.
820 Gbit/s
Performance:
410 Gbit/s
Size of the address table:
The size of the address table for this configuration, expressed in the number of entries.
32,000 entries
Static route:
Yes
Compatible with Jumbo Frames:
Yes
Jumbo Frames Extension:
9000
Features
Certificates:
CE, FCC, VCCI, BSMI
Security
DHCP Features:
DHCP server
Access Control List (ACL):
Yes
IGMP snooping:
Yes
protection against entering an infinite loop:
Yes
Network
10G support:
The product may use Oracle 10G, a database management system released in 2003.
Yes
Communication Standards:
Network standards, e.g., IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.
IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3az, IEEE 802.3by, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Port duplication:
Yes
Quality of Service (QoS):
Yes
Auto-Negotiation:
Yes
VLAN support:
A virtual local area network (VLAN) consists of several computers and switches. It is a computer network that is logically separated within another, larger physical LAN.
Yes
Management Features
Switch type:
The type of switch the device has.
Managed
Switch layer:
A network switch is a networking device that connects segments of a computer network. A switch has several layers, including Layer 2 (network bridge, connecting a small number of devices) and Layer 4 (m.in. acts as a firewall).
L2
Management via the website:
Using a web application to manage specific tasks.
Yes
Reset button:
Yes
System Events Report:
Yes
Device software updates:
Yes
Ports and Interfaces
Console port:
RJ-45
Number of SFP28 ports:
16
Number of ports:
Number of cable sockets.
16
Performance
Fiber-optic connector:
A fiber optic connector that allows for faster connection and disconnection than splicing. The connectors automatically engage and align the fiber cores so that light can pass through them. Higher-quality connectors lose very little light due to fiber reflection. In total, approximately 100 types of optical fibers have been manufactured.
SFP28
Structure
Stackable product:
Devices that can be stacked on top of each other.
No
Rack-mounting options:
A type of mounting that secures devices to shelves and stands.
Yes
Product color:
Color, e.g., red, blue, green, black, white.
Black
Power
Power adapter included:
A power adapter is included with the product.
Yes
Power source:
The device’s power source, e.g., mains voltage.
Alternating current
AC input voltage:
Electrical voltage.
100 - 240 V
AC input frequency:
50 - 60 Hz
Maximum power consumption:
The maximum amount of power the device consumes.
80 W
Ergonomics
LEDs:
Operation, Link, Power, Speed, Status
Weight and Dimensions
Product weight:
Product weight without packaging (net). Whenever possible, the net weight is listed together with the weight of the equipment’s standard accessories. Please note that some manufacturers define the product weight as that of a single unit, excluding the weight of accessories and/or supplies.
2.15 kg
Product depth:
Distance from the front to the back of the item.
237.7 mm
Product height:
Product height.
43.5 mm
Product width:
Width measurement.
285 mm
Packaging data
Weight including packaging:
Weight of the packaged product in grams.
2.85 kg
Package width:
The distance from one side of the package to the other.
384 mm
Package depth:
Distance from the beginning to the end of the package.
282 mm
Package height:
Distance from the top to the bottom of the package.
78 mm
Package type:
Product packaging type, e.g., box.
Box
Package Contents
Quick Start Guide:
Instructions, available both online and in print, that allow for quick installation and use of the product.
Yes
Cables:
Alternating current
Hook Installation Kit:
Yes
Working Conditions
Temperature range (operating):
The minimum and maximum temperatures at which the device can be used safely.
0–40 °C
Relative humidity range:
5 - 95%
Logistics data
Country of origin:
Country where the product was manufactured.
Taiwan
Harmonized System (HS) code:
85176990
Products in the main (outer) box:
5 items
Technical Details
Warranty Period:
2 years
Other features
EMC Standards:
A list of countries and their respective regulatory agency standards with which the product complies.
CLASS A
