VIVOLINK
Vivolink VL120021 KVM Extender Transmitter and Receiver
Transmitter and receiver
Wired Maximum transmission distance: 100 m
Transmitter video port type: HDMI Local keyboard/mouse transmitter port type: USB
Power consumption (transmitter) (max): 18 W Power consumption (receiver) (max): 18 W
Specification
Mouse
Communication technology:
The technology that enables the device to connect, e.g., wired or wireless.
Wired
Features
Model:
Device features.
Transmitter and receiver
Easy installation:
Yes
Display
Maximum refresh rate:
60 Hz
Assembly
Number of supported displays:
The number of displays that can be used with this product.
1
Network
Supported cable types:
Cat6a
Ports and Interfaces
USB data transfer speed:
200 Mbit/s
Video recording interface:
HDMI
Number of RJ-45 ports (transmitter):
1
Number of USB 2.0 ports:
USB 2.0 ports have a data transfer rate of 480 Mbps and are backward compatible with USB 1.1. Various types of peripheral devices can be connected to them.
3
USB port type:
USB Typu-A
Port RS-232:
Number of RS-232 ports. The RS-232 serial port was once a standard feature of personal computers, used for modems, printers, mice, uninterruptible power supplies, and other peripheral devices. Today, this port has largely been replaced by USB and other ports.
1
HDMI version:
2.0
Performance
Maximum transfer distance:
The maximum distance over which data can be transmitted.
100 m
Supported resolutions:
1280x800 4:4:4
Structure
Product color:
Color, e.g., red, blue, green, black, white.
Black
Power
AC input voltage:
Electrical voltage.
100 - 240 V
AC adapter output current:
2 A
AC adapter output voltage:
12 V
Power consumption (transmitter) (max):
18 W
Ergonomics
Plug & Play support:
Indicates whether a given product supports the "plug & play" feature. Plug & play refers to a type of device or software that can be used immediately after being connected, as opposed to devices or software that require configuration.
Yes
LEDs:
Link
Indoor unit
Power consumption (device) (max):
18 W
Weight and Dimensions
Transmitter width:
11.6 cm
Transmitter depth:
9.5 cm
Transmitter height:
2.2 cm
Product weight:
Product weight without packaging (net). Whenever possible, the net weight is listed together with the weight of the equipment’s standard accessories. Please note that some manufacturers define the product weight as that of a single unit, excluding the weight of accessories and/or supplies.
500 g
Transmitter weight:
197 g
Receiver width:
11.6 cm
Receiver depth:
9.5 cm
Receiver weight:
2.2 cm
Receiver weight:
198 g
Packaging data
AC power adapter:
Yes
Weight including packaging:
Weight of the packaged product in grams.
818 g
Package width:
The distance from one side of the package to the other.
183 mm
Package depth:
Distance from the beginning to the end of the package.
161 mm
Package height:
Distance from the top to the bottom of the package.
128 mm
Package Contents
Mounting bracket included:
Yes
User Manual:
Yes
Types of power plugs included in the set:
EU
Transmitter
Video-type transmitter port:
HDMI
Local video transmitter port:
Yes
Local keyboard/mouse transmitter port type:
USB
Working Conditions
Temperature range (operating):
The minimum and maximum temperatures at which the device can be used safely.
-10 to 55 °C
Relative humidity range:
10 - 90%
Other features
Product dimensions (WxDxH):
Product dimensions (Width x Depth x Height) expressed in millimeters.
116 x 95 x 22 mm
Number of RJ-45 ports:
1
